Dump Truck
Properties
Hydrema's 912G series is engineered to perform tasks in the rough off-road terrain. The series presents the 912G, 912GS, and 912HM - all with articulated steering for superior maneuverability. These machines are not only light in weight but also powerful in operation, ensuring long durability and reliability in even the most demanding conditions. Perfectly adapted for diverse construction sites and demanding terrains, they offer long-lasting efficiency and performance.
The upgraded Hydrema 912GS takes operator comfort and machine performance to a new level. With an advanced suspended front axle, equipped with an electro-hydraulic suspension system, this dump truck sets new standards for comfort within its class. This improvement is particularly notable on uneven terrain and over long driving distances. With the 912GS version, you get a hauler that not only gets the job done, but does it with unrivalled operator comfort.
The Hydrema 912GS continues the legacy of the 912G with a robust 4.5 liter turbodiesel engine that produces 147 hp and integrates emission-reducing technology such as DOC, DPF and SCR catalysts with AdBlue addition. Designed to meet the strictest environmental standards and with the ability to run on biodiesel, the 912GS is a sustainable choice for the future.
The energy from the Hydrema 912GS's engine is flawlessly transmitted through the sophisticated ZF WG 115 6-speed "ERGO POWER" Soft-Shift transmission. This transmission's 100% electronic control enables seamless gear changes and a constant flow of power, ensuring no power is lost even in the most demanding situations. With its wide range of gears and the user-friendly ability to switch between automatic and manual steering, the 912GS offers drivers unrivalled control. The constant 4-wheel drive ensures solid traction on all kinds of surfaces, making the 912GS the ultimate partner for complex and demanding construction projects.
The Hydrema 912GS's chassis takes exceptional stability to new heights with its central articulated steering, combined with a suspended front axle system that effectively absorbs shocks from the terrain. Its sophisticated suspension system includes two independent hydraulic cylinders that automatically adjust to the weight of the load and the challenges of the terrain. Integrated into the chassis design, the fuel and hydraulic tanks located in the front contribute to a low centre of gravity that further improves stability. For precise control, even in difficult conditions, oscillation movements can be locked, making the 912GS a reliable partner on challenging terrain with its superior oscillation angle.
With the 912GS, you get the added benefit of a suspended front axle system that provides superior operator comfort compared to the 912G's direct and robust design. The advanced planetary reduction gears in the wheel hubs and specially designed separate oil chambers remain, ensuring the model's reliability and durability. At the same time, the front axle has been upgraded with an advanced suspension mechanism, while the rear axle continues to offer the electro-hydraulic 100% differential lock for unrivalled off-road performance.
The 912GS is equipped with a ZF WG 115 6-speed "ERGO POWER" Soft-Shift transmission, optimized for improved comfort and stability from its new suspension. This system ensures smooth gear changes and constant traction via electronically controlled clutches. With 6 forward and 3 reverse gears, plus constant four-wheel drive, you can easily customize between automatic and manual operation with joystick buttons for an efficient and smooth drive.
Discover the Hydrema 912GS's engine, the powerful Cummins B-4.5L Stage 5 engine and its advanced emission systems. This state-of-the-art engine is equipped with advanced emission control technology, including DOC, DPF, and SCR systems, further enhanced with AdBlue. Immerse yourself in the impressive power of a 4.5-litre, 16-valve common-rail turbodiesel engine, complete with intercooler and an electronically variable turbocharger, delivering up to 147 hp (108 kW) at 2000 rpm. Enjoy the powerful 600 Nm (442 lb. ft) of torque at just 1500 rpm. And with the option to run on biodiesel, you're not only choosing power, but sustainability too.
Achieve precise maneuvering with our advanced Load Sensing articulated steering. Equipped with two efficient dual-acting cylinders, it ensures responsive steering with emergency steering function and damped steering cylinders. Enjoy exceptional maneuverability with a maximum steering angle of +/- 35°.
The Hydrema 912GS utilizes an advanced hydraulic pump that adapts to the dynamics of the suspension system to ensure stable and efficient operation. The system supports the tipping function and other demanding hydraulic needs with increased performance and accuracy.
Experience the peace and comfort the Hydrema 912GS offers, where a suspended chassis significantly reduces vibration and noise levels. Inside the cab, a low sound level of only 72 dB(A) is maintained, ensuring a relaxed working atmosphere, while the exterior noise level is limited to 102 dB(A), reflecting the machine's innovative and considerate design towards the surrounding environment.
The electrical system of the 912GS matches its high-performance nature and is equipped with a standard 24V system boosted by a robust 70 Amp alternator. Two 12V, 95Ah batteries ensure a strong and reliable power supply, designed to support the additional functions provided by the suspension system.
Experience the convenience of our automatic battery isolator, which switches your machine's electrical system off and on automatically, with door sensor-activated restart and easy shutdown time setting from the instrument display. For added safety, there's an emergency switch at your fingertips in the operator's cab. Efficiency and safety at the touch of a button.
Your 912GS comes equipped with a generous 36.98 gallon diesel tank, so you can work longer without interruption. And to ensure cleaner operation and compliance with environmental standards, there's a 3.69 gallon AdBlue tank, elegantly integrated into the front of the chassis. Both tanks are designed to easily keep you on the road and contribute to a more sustainable future.
The 912GS's robust 7.3 yd3 body, made from robotically welded high-strength steel, proudly carries on the tradition of the 912G. With an impressive load capacity of 10 tons and a 75° tip angle for both rear tip and MultiTip, the improved suspension system delivers stability that allows full utilization of the body's capacity and durability - even under difficult load conditions. The truck's efficiency is further complemented by a fast tipping time of just 6 seconds, ensuring fast and efficient material handling.
Discover the freedom to manoeuvre with ease and efficiency with our optional MultiTip system offers a compact and fast unloading function that allows rear and side loading. The robust swivelling system, supported by a solid slewing ball bearing, ensures a smooth and reliable movement using two dual-acting cylinders. The tipping function, powered by powerful cylinders, guarantees safe and accurate unloading - no matter the terrain. Increase your productivity with MultiTip, bringing efficiency and versatility to any task.
The MultiChassis is the Hydrema 912GS' answer to application diversity, a true example of the versatility of the machine and available as an option for your Hydrema 912's. This universal chassis is designed to easily adapt to a wide range of modules, from water tanks and concrete mixers to salt spreader equipment, making it an ideal solution for customers looking for a multipurpose machine. With MultiChassis, the Hydrema 912GS can be easily transformed to meet the specific needs of different projects, increasing its value and efficiency on the jobsite.
For ultimate control and safety, our two-circuit hydraulic servo brake system features oil immersed brake discs on all wheels that are self-adjusting and completely maintenance-free. This system ensures consistently reliable braking power, even under the toughest working conditions. The electro-hydraulic activation of the wet disc brakes on the front axle guarantees a fail-safe parking brake for extra peace of mind wherever you work.
Discover comfort and safety with our spacious ROPS/FOPS approved cab that offers unrivalled visibility and safety. Choose between a mechanical or air suspension seat for customized comfort, and enjoy the fully adjustable steering wheel and intuitive multi-joystick controls for optimal control and efficiency. Designed in accordance with ISO standards 5006 & 14401, this cab is your guarantee of both comfort and safety in the workplace.
| STD. TIP | MULTITIP | MULTICHASSIS | ||
| Tyres | 600/55-26,5 | 600/55-26,5 | 600/55-26,5 | |
| Total weight | lbs | 38,669 | 39,683 | 39,683 |
| Unladen weight | lbs | 16,623 | 17,637 | 13,669 |
| Load capacity | lbs | 22,046 | 22,046 | 25,794 |
| Body capacity | ft3 | 8,213889 | 8,213889 | - |
| Turning radius | ft | 20’ | 20’ | 20’ |
| Ground pressure (loaded) | Psi | 17.84 | 18.13 | - |
| Suspended front axle | X | X | X | |
| Track | ft-in | 6’1” | 6’1” | 6’1” |
| Total width | ft-in | 8’1” | 8’1” | 8’1” |
| Clearance | ft-in | 1’6” | 1’6” | 1’6” |
| Dump truck body width | ft-in | 7’3” | 7’3” | - |
| Total height | ft-in | 9’2” | 9’2” | 9’ |
| Loading height | ft-in | 7’4” | 7’11” | - |
| Height with raised body | ft-in | 14’5” | 14’11” | - |
| Tipping clearance | ft-in | 3’8” | 4’2” | - |
| Overhang, rear | ft-in | 3’3” | 2’12” | - |
| Wheel base | ft-in | 10’1” | 10’1” | 10’1” |
| Length | ft-in | 19’6” | 19’3” | 18’6” |
| Approach angle, front | ° | 28 | 28 | 28 |
| Approach angle, rear | ° | 75 | 80 | - |
| Tipping angle | ° | 75 | 75 | - |
| Overhang, front | ft-in | 6’2” | 6’2” | - |
When you buy a Hydrema dump truck, you can choose to have it made in any color you like - the only limit is your imagination. Would you like your 912GS match your brands colors and feel? Or would you like it to be your favorite color? No problem, we'll make it just how you want it.
Get in touch with our sales team today and we'll help you make the machine of your dreams!
